| General | |
| Pan/Tilt/Rotation | Pan: 0 to 360°, Tilt: 0 to 180°, Rotation 0 to 360° |
| Power | 12 VDC +-25% |
| Power Consumption | Maximum 4.3 W |
| Weight | 330 gm |
| Camera | |
| Electronic Shutter Speed | PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
| Image Sensor | 5 MP CMOS |
| IR Distance | Up to 40m IR distance for bright night imaging |
| Minimum Illumination | 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Lens | |
| Angle of View | Pan: 0 to 360°, Tilt: 0 to 180°, Rotation 0 to 360° |
| Focal Length | 2.8 mm, 3.6 mm, 6 mm, 8mm, 12mm fixed focal lens |
| Lens Type | fixed focal lens |
| Mount Type | M12 |
| Video | |
| Day/Night | ICR |
| Resolution | 2560 (H) × 1944 (V) |
| Video Output | TVI/ AHD/ CVI/ CVBS |
| Physical Specification | |
| Dimensions | 78.9 x 75.4 x 216.6 mm |
| Warranty Information | |
| Warranty | 01 year warranty |
